The KDJ17 Series Pushbutton Switch Offers A Heavy Duty Industrial Design And Safety Protection

E-Switch announces the KJD17 series pushbutton switch. This heavy duty switch offers an industrial design and a PVC cap for dust and water protection, equivalent to an IP54 rating. The KJD17 series pushbutton switch has an electromagnet inside the switch that provides automatic safety protection against power outages and restarts. It is rated at 2HP and 16A, and is UL listed.

Specifications include:

  • Life Expectancy: 10,000 cycles
  • Contact Rating :

16A @ 12VAC
16A @ 220/240VAC
1/2HP 120 VAC
2HP 220/240VAC

  • Contact Resistance (Initial Max) : 50m O
  • Insulation Resistance: 100 M O min at 500VDC
  • Dielectric Strength: 1,500 VAC for 1 minute
  • Operating Temperature: -25°C to +55°C

The KJD17 series pushbutton switch is a great product for the industrial market, especially where safety is a concern.

Visit E-Switch at www.e-switch.com to request your full-line catalog! You can also request a sample of one of over 4,000 discrete part numbers for one of your projects!
